Suzhou Penny Machinery Equipment Ltd.,CO

G-Penny 1.5KW ER11 D65 110V/220V Air cooled 400hz-24000rpm 1.5KW H100 Inverter spindle motor kit

G-Penny 1.5KW ER11 D65 110V/220V Air cooled 400hz-24000rpm 1.5KW H100 Inverter spindle motor kit

$143.00 USD
$143.00 USD
Sale Sold out
Voltage

  • Size:65 x 204mm ( Body diameter:65mm;  Length:204mm)

  • Cooling:Air cooling

  • Power Interface:Optional H17-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.(Pay attention! our spindle "4" connecting to GND,promised personal safety!!)

  • Power:1.5kw (1HP=0.735kw)

  • Voltage:220vAC(If you need 110v/380v spindle ,please leave message to us,thank you)

  • Current:6A

  • Frequency:0-400Hz

  • Speed:0-24000rpm

  • Runout Off:0.01mm

  • Bearing Type:2X7002C P4 DT and 2X7002C P4 DT

  • Full sealed angular contact bearings

  • Collet:ER11

  • Clip Knifediameter: 7mm,6.35mm,6mm,5mm,4mm,3.175mm,3mm,2mm,1mm

  • Air Cooling ER11 collet chunk
