G-Penny 2.2KW ER20 D80 110V/220V/380V Air cooled spindle motor 400HZ 24000rpm 4pcs bearings wood working

Basia parameter:

Size: 80x224mm(Middle body diameter: 80mm x Length:224mm)

Speed Ways: Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.

Cooling: Air cooling

Power Interface: Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.

Power: 2.2kw

Voltage: 220v

Current: 10A

Frequency: 0-400Hz

Speed: 0-24000rpm

Runout Off: Less than 0.01mm

Diameter(mm): 80

Bearing Type: 2 x 7005 P4 DT & 2 x 7002 P4 DT

4pcs fully sealed angular contact bearings

Collet: ER20

Clip Knifediameter: 13mm,12mm,12.7mm,11mm,10mm,9mm,8mm,7mm, 6.35mm,6mm, 5mm, 4mm, 3.175mm, 3mm, 2mm, 1mm (standard 6mm)

Water Cooling ER20 collet chunk

Grease Lubrication

Main Application:Engrave for wood,bamboo,normal PCB,PVC,PMMA,plastic,duotone board(ABS)and etc nonmetal, also can engrave on gold,silver,copper, aluminium,Pb etc soft metal surface working.(Please pay more attention, this is wood working spindle, only can used for wood working and aluminum working,please don't use it for steel. If you need steel working,please check the metal spindle,thank you!)
