Suzhou Penny Machinery Equipment Ltd.,CO

G-Penny 2.2KW ER20 D80 Metal working 2.34N.m water cooled spindle motor 300hz 4000-9000rpm copper rotor high torque

G-Penny 2.2KW ER20 D80 Metal working 2.34N.m water cooled spindle motor 300hz 4000-9000rpm copper rotor high torque

Regular price $271.15 USD
Regular price Sale price $271.15 USD
Sale Sold out
Voltage

Basic parameter:

Size:100x251.2mm (Middle body diameter:100mmxLength:257.2mm)

Speed Ways:Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.

Cooling:Water cooling

Power Interface:Optional H20-4 pins waterproof air plug. The air plug marked "1 ","2"," 3"," 4", "1 ","2 ","3" were connected to inverter (U, V, W), 4 connected inverter ground.

Power: 2.2kw

Voltage: 220v/380v

Current: 10A/6A

Frequency:300Hz

Speed: 4000-9000rpm

Pole:4

Runout Off:Less than 0.01mm

Diameter(mm):80

4pcs Ceramic Ball Bearings (fully sealed angular contact bearings)

Collet:ER20
